Product Details
＋
Fujitsu 24,000 BTU 17.5 SEER Medium Static Pressure Duct Single Zone System is the perfect product to use to heat and cool a space where you'd like to hide the system but have limited above-ceiling space. This particular unit has enough static pressure to heat and cool very large areas or even a whole home. This system comes with an out of the box 7 year compressor / 5 years part warranty, 10 year warranty if its installed by a licensed HVAC tech and registered within 60 days, or a 12 year warranty if it's installed by a Fujitsu Elite contractor.
General Information
- Medium Static Ducted
- Cooling & Heating
- No
- 1
- 24,000 BTU
- 3/8" x 5/8"
Package Includes
- ARU24RGLX
- Remote Controller Not Included
- AOU24RGLX
Features
- Manage your unit from anywhere using FGAir - accessory wifi module needed (UTY-TFSXZ2)
- Static pressure up to .8" W.G, automatic static pressure detection for install conditions
- This system is perfect to heat/cool large areas
- Built-In Condensate Drain
- Uses Anti-corrosive coil coating on outdoor unit
Indoor Specs
- Moisture Removal: 4.0 Pt./h
- Air Circulation Modes: Hi, Medium, Low, Quiet
- Air Mode CFMs: 800, 636, 518, 400
- Indoor Sound Levels (dBs,Cooling/Heating): 35/35, 30/30, 28/28, 24/24
- Net Weight: 93 lbs
- Dimensions (HxWxD): 11 13/16", 39 3/8", 27 9/16"
- Compatible Controllers: Wired Remote Controller (UTY-RNRUZ), Simple Remote Controller (UTY-RSRY)
- Static Pressure in W.C.: 0.12-.80
Outdoor Specs
- Voltage: 208-230V
- Circuit Breaker: 30 Amps
- Net Weight: 134 lbs
- Dimensions (HxWxD): 32 11/16", 35 7/16", 13"
- Minimum Line-set Length: 16'
- Maximum Line-Set Length: 164'
- Max Vert Diff: 98'
- Outdoor Line-Set Ports: 3/8" x 5/8"
Performance
- 24,000 BTU
- Min-Max Cooling: 5,400-29,000 BTU
- 27,000 BTU
- Min-Max Heating: 5,400 - 32,400 BTU
- 17.5
- HSPF: 10.8
- EER: 12.6
- -5 F - 75 F
- 14 F - 115 F
- up to 1,000 sq ft
Certifications
- Yes
- Yes
- Yes
